The new Shelly 1 Gen4 is a small Matter, ZigBee, WiFi switch that allows you to easily switch and automate your lights or devices wirelessly. Also, the 4th generation Shelly 1 has a Dry Contact and the new ESP-Shelly-C68F chip with 8MB flash memory. The open source and multi-protocol ensures that you can integrate Shelly 1 Gen4 with almost any home automation system. But Shelly also has its own free App that allows you to easily and inexpensively set up a Smart Home System without the cost of a Gateway/Hub. Works with Apple HomeKit
Shelly 1 Gen4 with Matter and ZigBee
You connect this smart switch to your home network via Matter, ZigBee, or Wifi, and plug into the wall switch of the lamp or device you want to wirelessly control, automate and monitor. The Shelly 1 Gen4 supports 110-240VAC, 12VDC, 24-48VDC, max 16A/3680W, and has the new and proprietary ESP-Shelly-C68F chip with 8MB of flash memory built in. That's double compared to the Gen2 with ESP32 chip. Note; the Shelly 1 Gen4 also requires a blue neutral wire, which is sometimes missing behind the wall switch!
Also the 1 Gen4 works as a WiFi amplifier, Bluetooth Gateway, supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates.
We also have the Shelly 1PM Gen4 with Power Metering, or the Shelly 1 mini Gen4 8A/1840W.
Works with
FEATURES
Pros and cons
 |
Open source |
|
Works stand-alone via WiFi 2.4 Ghz |
|
Matter certified |
|
ZigBee 802.15.4 |
|
Bluetooth 5.0 for easy connection to WiFi |
|
WiFi amplifier and Bluetooth gateway |
|
Built-in Web server |
|
Access Point and Client Mode |
|
Supports HTTP and/or UDP |
|
Power Meter with Relay Switch |
|
Power supply 110-240VAC, 12VDC, 24-48VDC |
|
Max 16A/3680W total |
|
Over-voltage protection |
|
Max power protection |
|
Free Android of IOS App |
|
Free Shelly cloud |
|
Works with MQTT |
|
Easy installation |
|
Scene activation via App |
|
ESP-Shelly-C38F with 8MB flash/debug chip |
|
OTA frimware updates |
|
Dry Contact, free cloud storage |
|
2 Year Carry-in warranty |
 |
Requires a blue neutral wire |
DOWNLOADS
 |
Shelly 1 Gen4 Manual (ENG-Multi) |
|
Shelly add via Webbrowser (NL) |
|
Shelly REST API (ENG) |
| Voltage: | 110-240VAC, 12VDC, 24-48VDC |
| Power: | Max. 16A/3680W |
| Usage: | unknown |
| Protocol: | Matter, ZigBee 802.15.4, Wifi 2.4Ghz, Bluetooth 5.0 |
| Dimension: |
